Specifications with NEXO Processing

• Frequency Response (+6 dB)
  63 Hz to 20 kHz
• Sensitivity (1W@1m)
  107 dB SPL Nominal
• Peak SPL Level (1m)
  136 dB Peak
• Recommended Amplifiers
  550 to 870 Watts / 8Ω
• HF Dispersion (according to horn)
  100° x 100° (Default) – 110° x 60° (with 110° x 60° optional horn)
• Crossover Frequency
  63 Hz, 85 Hz, 120 Hz
• Nominal Impedance
  8Ω
• Recommended Power
  550 to 870 Watts into 8Ω

Features

• Components
  1 x Coaxial Neodymium LF 10” 8 Ohms long excursion & HF 1.7” 8 Ohms
• Number of ways
  2-way passive
• Connectors (Touring/TIS versions)
  4 x NL4, 4-pole connectors (1 per handle + 2 at the back)
• Connectors (Install version)
  1 x cable gland με 2-core καλώδιο
• Rigging points
  1 x universal accessory fit on each side + 1 x on the bottom
• Material
  Custom κατασκευή από λυγισμένο κόντρα πλακέ Baltic birch & poplar
• Finish
  Μαύρη ή λευκή δομική βαφή
• Front Finish (Touring version)
  Μεταλλική πρόσοψη Magnelis® + πίσω mesh
• Front Finish (Install/TIS versions)
  Ανθεκτική σε UV ακουστική υφασμάτινη πρόσοψη
• Height x Width x Depth
  497 mm x 384 mm x 274 mm (19.6” x 15.2” x 10.8”)
• Weight (Net)
  15 kg (33 lbs)
• Operating Temperature Range
  0°C – 40°C (32°F – 104°F)
• Storage Temperature Range
  -20°C – 60°C (-4°F – 140°F)

System Operation

• Recommended Powering Solution
  NXAMP4X1MK2 (1 x P10 per channel)
• Optional Powering Solution
  DTD + DTDAMP4X1.3 (Up to 2 x P10 per channel)
• Optional Powering Solution
  NXAMP4X2MK2 (Up to 4 x P10 per channel)
• Optional Powering Solution
  NXAMP4X4MK2 (Up to 4 x P10 per channel)
