Main Features

• DMX Channels
  3, 17 or 35
• DMX Connectors
  3-pin XLR
• Pan and Tilt
  540°/180°
• Colors
  (moving head)

Light Source

• pars
  6 LEDs (quad-color RGB + UV) 3.5 W (1 A), 50,000 hours life expectancy
• strobe
  4 LEDs (dual-color white + UV) 5 W (1.5 A), 50,000 hours life expectancy
• derby
  6 LEDs (2 red, 2 green, 2 blue) 5 W (1.6 A), 50,000 hours life expectancy
• moving head
  1 LED (cool white) 10 W (2.3 A), 50,000 hours life expectancy
• laser
  650nm/100 mW (red) laser diode, 532 nm/30 mW (green) laser diode

Specifications

• Strobe Rate
  (all effects)
• Beam Angle
  (moving head)
• Field Angle
  (pars)
• Coverage Angle
  (derby)
• Fits Tripod Size
  37.4 mm
• Illuminance
  (pars)
• Power Linking
  7 units @ 120 V; 12 units @ 230 V
• Input Voltage
  100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current
  81 W, 1.1 A @ 120 V, 60 Hz | 79 W, 0.6 A @ 230 V, 50 Hz
• Weight
  10.7 kg
• Size
  1100 x 144 x 449 mm
• Approvals
  CE, FDA, FCC
• Stand Height
  1.5 to 2.5 m
• Footswitch Operating Frequency
  433 MHz
• Footswitch Max Unobstructed Distance
  30.5 m
• Footswitch Battery
  9 V alkaline
• Included Controllers
  IRC-6, wireless
