The FOS Technologies Arena Zoom 10x40 IP65 is a high-performance professional moving LED bar, designed for demanding indoor and outdoor lighting applications. Equipped with 10x 40W RGBW LEDs, it delivers powerful output, vivid colors, and excellent light uniformity.

It features a motorized zoom range from 3° to 60°, allowing flexible use from tight beam effects to wide wash coverage. The 205° motorized tilt movement provides dynamic motion effects and high creative flexibility on stage.

The full pixel control function and dual zoom sections enable advanced effects, animations, and independent control of brightness and color, delivering impressive visual results. In addition, the variable CTO color temperature from 2,700K to 8,000K ensures excellent adaptation to both warm and cool lighting environments.

The 0–100% linear dimmer and strobe function up to 20Hz provide full control over intensity and effect rhythm, while the IP65 rating ensures reliable operation in outdoor conditions.

Light Source / Optics

• Features 10x 40W high-power RGBW LEDs with an estimated lifespan of approximately 50,000 hours.
• It incorporates two independently controlled zoom sections, with a beam angle range from 5.8° to 60°, offering high flexibility for both beam and wash applications.
• The variable color temperature ranges from 2,700K to 8,000K, allowing precise adjustment of warm and cool tones depending on production or environment requirements.

Effects

• Features a 205° motorized tilt movement, delivering dynamic motion effects and enhanced stage flexibility.
• The RGBW color mixing system ensures rich and vibrant color output, while the independent pixel control function allows separate control of each zone for creating stunning animations and lighting effects.
• The two independent zoom sections further enhance creative flexibility by enabling simultaneous variation of beam shape and lighting output.

Control

• Supports DMX, Master/Slave, Sound, and Auto control modes, providing flexible integration in any professional lighting setup.
• DMX control is available in 19, 28, 29, 33, 34, 48, and 49 channel modes, covering both basic and advanced programming and pixel control requirements.

Technical Specifications

• Power supply: 100–240V AC, 50/60Hz
• Power consumption: up to 400W
• Motorized zoom: 3°–60°
• Motorized tilt: 205° (16-bit)
• Full pixel control & 2-zone zoom
• CTO: 2,700K–8,000K
• Dimmer: 0–100% linear
• Strobe: up to 20Hz
• LCD display for menu navigation
• Connections: IP PowerCON in/out & 3-pin XLR DMX
• Dimensions: 607 × 122 × 351 mm
• Net weight: 15.5 kg
• IP65 rating for outdoor use
