Martin Audio Blackline Q12 Black
Martin Audio Blackline Q12 Black
- High performance – up to 133 dB peak SPL
- Powerful low-frequency response
- Differential Dispersion rotatable horn
- Flexible use (FOH, monitor, installation)
- Professional high-durability construction
- Full connectivity and installation flexibility
Do you have questions or want to order by phone?
Καλέστε μας στο 210 21 30 405 & 210 21 30 406
Related Products
With a maximum SPL of 127 dB (133 dB with a crest factor of 4), the BlacklineQ Q12 meets the demand for a compact loudspeaker capable of delivering high sound pressure levels — whether used as a standalone system or in combination with a BlacklineQ subwoofer.
It features a 12” (300 mm) low-frequency driver with a 2.5” (63 mm) voice coil, along with a high-frequency compression driver featuring a 1” (25 mm) exit and a 1.7” (43 mm) dome.
It incorporates a Differential Dispersion horn for wider and more consistent coverage, which can be easily rotated for horizontal or vertical orientation depending on deployment requirements.
Features
- Compact passive two-way system
- Symmetrical multi-angle plywood enclosure
- Peak SPL of 127 dB (133 dB with crest factor 4)
- User-rotatable Differential Dispersion horn
- Dispersion: 90°–110° horizontal × 50° vertical
- Vertical and horizontal orientation capability
- Screw-tight perforated steel grille with internal cloth backing
- Integrated ergonomic handle made from recycled ABS
- Pole-mount cover for a clean appearance when mounted on a stand
- Nominal impedance: 8 Ω
- Two NL4 connectors
- Flexible mounting options via M8 inserts
Applications
- Portable professional sound reinforcement
- Live music clubs
- Bars and restaurants
- Nightclubs
- Discreet stage monitoring
- Corporate AV events and conferences
- Weddings and events
- Main PA infill
- Secondary festival stages
- Houses of worship, leisure centres, and retail spaces
Specifications
-
TypeCompact, passive two-way loudspeaker
-
Frequency response [1]56 Hz – 17 kHz ± 3 dB, -10 dB @ 45 Hz
-
Driver (LF)12” (300 mm) with 2.5” (63 mm) voice coil, ferrite motor system
-
Driver (HF)1" (25 mm) exit compression driver with 1.7" (43 mm) voice coil
-
Rated power [2]300 W AES, 1200 W peak
-
Required electronicsProcessor and amplifier, or a combined amplifier-processor unit
-
Recommended electronicsDX0.4, DX0.6 or DX4.0 system processor and VIA amplifier, or iKON amplifier-processor
-
Sensitivity [3]96.5 dB
-
Maximum SPL [3]121 dB continuous, 127 dB peak, 133 dB peak with crest factor 4
-
Nominal impedance8 ohm
-
Dispersion90°–110° (horizontal) × 50° (vertical)
-
HornUser-rotatable Differential Dispersion horn
-
Crossover2.7 kHz passive
-
EnclosureSymmetrical multi-angle plywood
-
FinishBlack textured paint
-
Protective grilleBlack perforated steel grille with scrim cloth backing
-
Connectors2 x NL4 connectors
-
Pin connections (input)1+/1–
-
Pin connections (link)1+/1– to 1+/1– and 2+/2– to 2+/2–
-
Fittings16 x M8 inserts, 6 x M8 inserts for wall bracket
-
Handle1 x bar handle with recycled ABS pocket
-
Pole-mount socketWith removable cover
-
Dimensions(W) 358 mm x (H) 600 mm x (D) 321 mm
-
Dimensions (imperial)(W) 14.1 in x (H) 23.6 in x (D) 12.7 in
-
Weight18.4 kg (40.6 lbs)
