Digital Stagebox 16 In / 8 Out with 16 Midas PRO Microphone Preamps, ULTRANET, and ADAT Interfaces

Specifications

• 16 award-winning Midas PRO microphone preamps with switchable 48 V phantom power
• 8 electronically balanced, low-impedance line outputs
• ULTRANET system connectivity for personal monitoring in in-ear applications
• Digital audio and control connection for Turbosound speaker systems with ULTRANET networking capability
• Dual AES50 SuperMAC ports for cascading DL16 stageboxes — no merger or router required
• Dual ADAT outputs providing 16-channel digital output via two TOSLINK optical connectors*
• Remote operation via shielded CAT5e cable up to 330 ft / 100 m
• All settings programmable from the front panel controls or via the mixing console
• Status indicator LEDs on the front panel
• Headphone output assignable to any input or output for local monitoring
• MIDI In/Out for bidirectional communication between MASS M32 series consoles and MIDI devices
• Neutrik etherCON* AES50 and ULTRANET network ports
• Rugged 2U chassis designed for durability in portable applications
• Auto-ranging universal power supply
