Soundsation MioMix 202UFX
Soundsation MioMix 202UFX
4-Channel Analog Audio Mixer with USB and Digital Effects
- 24-bit digital effects with 16 presets
- 24-bit/96kHz USB audio interface
- Hi-Z input for direct guitar connection
- +48V Phantom Power for condenser microphones
- Ideal for home studios, live performances and podcasting
Code: 28592
Warranty:
2 Years
Out of stock
115,00€
Quantity:
Do you have questions or want to order by phone?
Καλέστε μας στο 210 21 30 405 & 210 21 30 406
SOUNDSATION MIOMIX 202UFX | 4-Channel Audio Mixer with USB & Effects
A 4-channel audio mixer featuring built-in digital multi-effects and a USB audio interface, ideal for small home studios, live performances, and podcasting applications that require professional audio quality and excellent portability.
Design
- Equipped with two microphone inputs featuring low-noise preamps, the MIOMIX 202UFX supports all major audio source types, including condenser microphones (thanks to +48V phantom power), dynamic microphones, line-level signals, and high-impedance (Hi-Z) instruments such as electric guitars and basses.
- The stereo line input allows connection of external devices such as keyboards, CD players, DJ mixers, tablets, and smartphones.
- The built-in 24-bit/48kHz digital effects processor offers 16 popular presets, including Hall, Room and Plate Reverb, as well as Delay, Echo, Chorus, and more.
- The Tap Tempo function lets you synchronize effects to the beat and adjust up to two parameters for each effect, providing greater flexibility during live performances.
- The integrated 24-bit/96kHz stereo USB audio interface (In/Out) enables easy connection to a computer for high-quality audio recording and playback.
- It is a reliable and essential solution for a wide range of small-scale audio applications.
Specifications
-
Input ConnectionsBalanced XLR/Jack Combo (Channel 1-2), Balanced ¼” Jack (Channel 3-4)
-
Output ConnectionBalanced XLR (Main Out L-R), Stereo ¼” Jack (Phones)
-
USB ConnectionType-B, Female
-
Channel 1-2 Functions+48V Phantom Power, Impedance Switch (Line/Hi-Z), 2-Band EQ (80Hz/12kHz ±15dB), Effect Send Level, Pan Position, Channel Volume, Peak LED Indicator
-
Channel 3-4 FunctionsImpedance Switch (+4/-10dB), 2-Band EQ (80Hz/12kHz ±15dB), Effect Send Level, Pan Position, Channel Volume, Peak LED Indicator
-
USB I/O SoundcardUp to 24-bit/96kHz Stereo Input/Output Streaming, USB Class 2.0 Compliant
-
Digital Effect24-bit Sigma-Delta, 256x Oversampling, 48kHz Sampling Rate
-
Level Meter2 × 6-LED Meter
-
Max Output Level3 Vrms
-
Frequency Response±0.5dB, 20Hz-20kHz
-
Dynamic Range102dB
-
THD+N @ 1kHz≤0.003%
-
Stereo Crosstalk92dB
-
Power RequirementsDC 5V, 1A
-
Power ConsumptionMax. 2.5W
-
Power Adapter100-240Vac – 0.15A / 5V DC – 1A Max (Power Adapter Included)
-
Dimensions166 × 165 × 66mm
-
Net Weight0.9kg
