Compact Stereo Amplifier

Features a Dante™ AES67 network input and delivers 2 x 30 W or 60 W in bridged mode

It can be powered entirely via Ethernet cable (PoE), maximizing flexibility and minimizing cabling requirements

The AMP203 includes DSP functionality, allowing configuration through AUDAC Touch™ 2 or via RS485 and Ethernet

Its compact enclosure eliminates any fan noise or hum, while a variety of optional mounting brackets allow installation under a desk, in a cabinet, on a wall, above a ceiling, or in a 19″ equipment rack

Specifications

System specifications

• RMS/AES power handling
• @ 2 Ω Bridge: 1 x 60 W
• @ 4 Ω Stereo: 2 x 30 W
• @ 4 Ω Bridge: 1 x 60 W
• @ 8 Ω Stereo: 2 x 30 W
• @ 8 Ω Bridge: 1 x 30 W
• THD+N (@ 1 kHz): < 0.015%
• Crosstalk (@ 1 kHz): < -98 dB
• Efficiency: > 70%
• Cooling: Convection cooled
• Control: RS-485, TCP/IP
• Power: PoE 802.3bt | Supply: 24 V DC

Inputs

• Type: 1 x Ethernet | RS-485 | Dante™/AES67 (4 channels)
• Connector: RJ45

Protection

• Over heating
• Over load
• DC Short circuit
• Signal limiting

Outputs

• Type: 1 x Stereo Loudspeaker | 1 x Line output
• Connector: 4-pin Euro Terminal Block (Pitch - 5.08 mm) | 3-pin Euro Terminal Block (Pitch - 3.81 mm)

Power

• Power Consumption: 80 W (max.)
• Nominal (1/8 MUP): 10.6 W
• Standby: 3 W
• Idle: 6.6 W

Product Features

• Dimensions: 108 x 44 x 165 mm (W x H x D)
• Weight: 0.7 kg

Recommended applications

• Bars & Restaurants
• Education
• Retail
• Corporate
• Residential
