Optimal Audio Zone 4
Optimal Audio Zone 4
- 4-zone audio processor with built-in DSP
- Flexible signal routing
- WebApp for easy system configuration
- 2 mic, 4 stereo line and 2 HDMI inputs
- Programmable presets
- Professional performance for multi-zone installations
Do you have questions or want to order by phone?
Καλέστε μας στο 210 21 30 405 & 210 21 30 406
Related Products
Zone 4 is a zonal audio controller with DSP providing everything required in a single compact unit to become the beating heart of an efficient, high-quality multi-zoned commercial sound system.
It allows the user to independently allocate sources across four configurable zones, such as a lobby, bar or restaurant, and each zone can be configured to do precisely what is required using the intuitive WebApp. This includes EQs, speaker presets, structured time of day routines and so much more.
Zone 4 features 4 line and 2 mic inputs plus 2 HDMI inputs for TV and video sound.
It has been designed to work seamlessly with other products in the Optimal Audio range and when coupled with ZonePad and SmartAmp series provides a simple, intuitive and cost-effective audio system with superb sound quality.
Features
- Full suite of audio controls for up to 4 zones
- Fully flexible signal routing
- WebApp interface for easy system configuration and everyday control
- 2 mic, 4 stereo line and 2 HDMI inputs
- Fully programmable presets and timed events
- Very competitive pricing
Specifications
-
Type4 zone audio processor with DSP and loudspeaker presets
-
Mic Inputs2 with 48V phantom power, +12dB to +55dB gain
-
Mic Input Processingfixed hi-pass filter @160Hz; sweepable mid-band 200Hz–5kHz ±12dB; HF shelf @12kHz
-
Line Inputs4 stereo with +26dB gain trim, SPDIF option on input 1
-
HDMI Inputs2
-
Line Outputs4
-
ZonePad Sockets4
-
Paging Inputs (CAT 5)2
-
LAN Ethernet100Mbps
-
Alarm OverrideYes
-
Dimensions480 x 88 x 400 mm (W x H x D)
-
Weight9.2 kg
