Ortofon OM 5E
Ortofon OM 5E
Ελλειπτική κεφαλή πικάπ
- Τύπος Ελλειπτική
- Tracking force 1.75 g
- Output voltage 4 mV
- Frequency response - 20-20.000 Hz
Code: 18714
Available in 4 - 10 days
75,00€
Quantity:
Add to cart
Do you have questions or want to order by phone?
Καλέστε μας στο 210 21 30 405 & 210 21 30 406
Products
Συνδύασέ το με
Products
Related Products
Ελλειπτική κεφαλή πικάπ
Χαρακτηριστικά
- Output voltage at 1000 Hz, 5cm/sec. - 4 mV
- Channel balance at 1 kHz - 2 dB
- Channel separation at 1 kHz - 22 dB
- Channel separation at 15 kHz - 15 dB
- Frequency range at - 3dB - 20-25.000 Hz
- Frequency response - 20-20.000 Hz ± 2 dB
- Tracking ability at 315Hz at recommended tracking force *) - 65 µm
- Compliance, dynamic, lateral - 20 µm/mN
- Stylus type - Elliptical
- Stylus tip radius - r/R 8/18 µm
- Tracking force range - 1.5-2.0 g (15-20 mN)
- Tracking force, recommended - 1.75 g (17.5 mN)
- Tracking angle - 20°
- Internal impedance, DC resistance - 750 Ohm
- Internal inductance - 450 mH
- Recommended load resistance - 47 kOhm
- Recommended load capacitance - 200-500 pF
- Cartridge colour, body/stylus - Black/Black
- Cartridge weight incl. extra weight - 5 g
- Cartridge weight excl. extra weight - 2.5 g
- Replacement stylus unit - Stylus 5E
-
ManufacturerOrtofon
